Lab 4: Vec — A First Dynamic Data Structure

Objectives

In this exercise, you will:

  1. Build a class that uses dynamic allocation/deallocation.
  2. Use pointer variables to access items in a dynamically-allocated array.

Introduction

You should know how to get the assignment. So, do it.

The Vec class is a simpler version of the vector<T> class template available in the C++ standard template library (STL). It will provide the basic functionality, without some of the more advanced “bells and whistles” of the STL version.

The class in Vec.h is a mere shell at this point. Filling in this shell is our task this week.

Step 1. Getting Started

Open each file and take a moment to browse through them, to get a sense of what each one contains. Note that test.cpp contains tests for a variety of Vec operations.

Our approach today will be to use the following steps to build each operation:

Step 2. Instance Variables

If you look in Vec.h, you’ll see that we are (for now) using a typedef to define the identifier Item as a synonym for the type double.

You’ll also see that the private: section of class Vec is currently empty. As a minimalist dynamic array, our Vec will need to “remember” two things:

  1. How many Items it is currently storing; and,
  2. The Items it is currently storing.

To let a Vec “remember” the first of these, add an instance variable named mySize of type unsigned:

private:
    unsigned mySize;

To let a Vec “remember” the second of these, add an instance variable named myArray capable of storing the address of an Item:

private:
    unsigned mySize;
    Item   *myArray;

With these two variables, a Vec object can “remember” (i) how many items it is storing, and (ii) the address of a dynamically allocated array in which its items are stored.

Step 3. The Default Constructor

The role of the default constructor is to provide the instance variables with default values. In a data structure, these are usually values that are appropriate for an “empty” structure. In Vec.cpp, complete the default constructor for the class, so that it sets mySize to zero, and sets myArray to nullptr. Compile and run the project (make tester && ./tester).

The test should pass, but notice that it isn’t actually doing anything... To make a useful test, we need to see if mySize is 0 and myArray is nullptr. However, myArray and mySize are private, so the test cannot “reach into” the innards of the Vec object to check the values. To resolve this, we will create a getter for mySize. In the .h file, in the public: section, add the prototypes:

unsigned getSize() const;

In the Vec.cpp file, add this code:

unsigned Vec::getSize() const {
}

and finish the code which returns mySize.

Uncomment the lines in the first (“default”) SECTION and compile and run (make tester && ./tester). You should get 1 assertion in 9 test cases passed.

Step 4. The Explicit-Value Constructor

The explicit-value constructor’s role is to initialize an object using values provided by the user. In a data structure, the user often wants to specify a non-zero starting size for the structure. (e.g., Vec v(5); should construct v as a vector capable of storing 5 items.) To store the value the user specifies, our constructor will need a parameter, so we might start by writing this stub for the constructor:

Vec::Vec(unsigned size) {
}

Put the above code in your .cpp file, and add a prototype for this constructor to the Vec class in Vec.h. Then in tests.cpp, uncomment ONLY THE FIRST 2 LINES OF CODE in the “explicit-value” SECTION that tests this constructor (if you hadn’t changed the tests.cpp file, those should be lines 14-15). Save/compile/run the tests. The test should fail. To make it pass, add code to your explicit-value constructor. Here is the algorithm to follow:

  1. Set mySize to size
  2. If size is positive (greater than zero):
    • Dynamically allocate an array of size values of type Item, and store the address of the array in myArray; and
    • Set each of the Items in that array to zero.
  3. Otherwise:
    • Set myArray to nullptr.

Continue when your class passes all tests (2 assertions in 9 test cases).

Step 5. Getting the Value of an Item

The rest of the test for the “explicit-value constructor” looks to see if myArray was initialized correctly. In order to do this, we need to be able to retrieve the value in each location in myArray. To do that, we’ll implement a getItem() method that lets us retrieve the value of an item at a given index (e.g., Item it = v.getItem(i);). Since this method (i) needs the index of the value it is to retrieve, and (ii) does not change its receiver’s instance variables, we will start by defining this stub:

Item Vec::getItem(unsigned index) const {
}

Place a prototype for this method in the Vec class, and in tests.cpp, uncomment the rest of the test code in the “explicit-value” constructor SECTION. For the sake of time, here is the code for .cpp file:

Item Vec::getItem(unsigned index) const {
    if (index < 0 || index >= mySize) {
        throw range_error("Bad index");
    }
    return myArray[index];
}

When all tests pass, continue (15 assertions in 9 test cases).

Step 6. Setting the Value of an Item

Our next operation is to set the value of a particular item in a Vec (e.g., v.setItem(i, val);). Since the method needs both the index of the item to change, and the new value for the item, we will start with this stub:

void Vec::setItem(unsigned index, const Item& it) {
}

Place a prototype for this method in the Vec class, and in tests.cpp, uncomment the code to test TEST_CASE("setItem") (22 assertions in 9 test cases).

Try to build and run the test to see what errors you get; then complete the stub so that it passes the test. Again, for the sake of time, here is the code for Vec.cpp.

void Vec::setItem(unsigned index, const Item& it) {
    if (index < 0 || index >= mySize) {
      throw range_error("Bad index");
    }
    myArray[index] = it;
}

When all tests pass for testing setItem, also uncomment the TEST_CASE("getItem"). If you have everything working, you should be passing 29 assertions in 9 test cases.

Step 7. The Copy Constructor

The compiler invokes a special copy constructor any time it needs a copy of an object, for example:

The C++ compiler supplies a default copy constructor, but it merely does a bit-by-bit copy of the instance variables of the object being copied. This bit-copy is inadequate for classes with pointer instance variables, because it just copies the address within such variables, rather than making a distinct copy of the dynamically allocated memory to which that address points. Because of this, every class that contains a pointer instance variable should define its own copy constructor that makes a distinct copy of the object, including its dynamically allocated memory.

The stub for a Vec copy constructor looks like this:

Vec::Vec(const Vec& original) {
}

Add the code above to the .cpp file. Then, add a prototype to the Vec class, and in tests.cpp uncomment the code in the “copy” constructor SECTION (SECTION("copy")) to test it. Then add statements to your stub to construct a Vec that is a distinct copy of original, and check to see if the tests pass. Here is the algorithm to follow:

  1. Set mySize to the size of original
  2. If original.mySize is greater than zero:
    1. Dynamically allocate an array of mySize values of type Item, and store the address of the array in myArray.
    2. Set each item~i~ in the new array to item~i~ from original.
  3. Otherwise, set myArray to nullptr.

Continue when your constructor passes all tests. (I am now seeing 42 assertions in 9 test cases passing.)

Step 8. The Destructor

The C++ compiler invokes an object’s destructor when the object ceases to exist. The role of the destructor is thus to perform any “clean up” actions that are needed to return the system to the same state it was in before the object existed. In a data structure that uses dynamic memory allocation, the main task is usually to return dynamically allocated memory to the system using the delete operation.

A destructor cannot have any parameters, and its name is the name of the class preceded by the tilde character (~), so we can begin with the stub:

Vec::~Vec() {
}

Skeleton code is already in the .h and .cpp files. Uncomment the code to test the destructor in tests.cpp. Then add the statements to the destructor to reclaim the dynamic array whose address is in myArray, set myArray to nullptr, and set mySize to zero. Compile and see if your statements pass the test. Here is the algorithm to follow:

  1. Use delete [] to deallocate the array whose address is stored in myArray: delete [] myArray;
  2. Set myArray to nullptr
  3. Set mySize to zero.

Technically, only the first step is strictly necessary. The reason is that the destructor is only invoked at the end of an object’s lifetime. Since the object will no longer exist, resetting its instance variables is not necessary (except to pass the test).

Continue when your destructor passes all tests, including the section TEST_CASE("destructor"). By now, you should have 43 assertions in 9 test cases.

Step 9. Setting a Vec’s Size

Our next operation is to set a Vec’s size via a method (e.g., v.setSize(8);). The role of this method is to allow us to change the size of an existing Vec to some new size. Since the user must specify this new size, we need a parameter to store it. We might start by defining this stub:

void Vec::setSize(unsigned newSize) {
}

Place a prototype for this method in the Vec class, and in tests.cpp, uncomment all the code in the TEST_CASE("setSize"). Then complete the stub so that it passes the test. Think carefully! This one is deceptively tricky to get right! Algorithm:

1. If `mySize` and `newSize` are different:
    a. If `newSize` is zero:
        1. Deallocate `myArray`
        2. Set `myArray` to `nullptr`
        3. Set `mySize` to zero.
    b. Otherwise:
        1. Declare a local variable `newArray` of type `Item *`
        2. Allocate a new dynamic array of `newSize` Items, storing its address in `newArray`.
        3. If `mySize` is less than `newSize`:
            1. Copy `mySize` values from `myArray` into `newArray`.
            2. Set the remaining (`newSize - mySize`) values to zero.
        4. Otherwise, just copy `newSize` values from `myArray` into `newArray`.
        5. Set `mySize` to `newSize`.
        6. Deallocate `myArray`.
        7. Set `myArray` to `newArray`.

When your method passes all tests (67 assertions in 9 test cases), continue.

Step 10. Equality

The purpose of the equality operation is to let us compare two objects (e.g., if (v1 == v2) { ... }), returning true if they are equal, and returning false if they are not. Since the equality operation returns a bool value, a call:

v1 == v2

will be treated by the compiler as:

v1.operator==(v2)

This equality operator should not change either of its operands. We start by defining this stub:

bool Vec::operator==(const Vec& v2) const {
}

Place a prototype for this method in the Vec class, and in tests.cpp, uncomment the code to test “equality” (TEST_CASE("equality")). Then add statements to the stub so that it passes the test. Algorithm:

  1. Check to see if mySize is NOT the same as the size of v2. If the two vectors are not the same size, return false.
  2. Compare each item~i~ in myArray to each item~i~ from v2’s array: If any are not equal, return false.
  3. The two arrays are equal in size, and all their values are the same, so return true.

Continue when your method passes all tests. By now you should have 74 assertions in 9 test cases.

Step 11. ostream Output

It is useful to be able to write a vector to an ostream, as this allows us to display it on the screen (or write it to a file via an ofstream). This method should output the values of the items in the Vec, but not its size; if the user wants that size information displayed, they can do that separately using getSize().

Whereas (i) our method returns nothing to its caller, (ii) it needs to “know” the ostream to which it is to write, (iii) it modifies that ostream by inserting items, and (iv) it should not modify any Vec instance variables, we might begin with this stub:

void Vec::writeTo(ostream& out) const {
}

Place a prototype for this method in the Vec class, and in tests.cpp, uncomment the test “writeToStream” (TEST_CASE("writeToStream")). Then add statements to this stub so that it passes the test. Algorithm:

Continue when your method passes all the tests (75 assertions in 9 test cases).

Step 12. istream Input

It is also useful to be able to read a vector from an istream, as this lets us enter a vector’s values interactively, from a keyboard (or read them from a file via an ifstream). This method complements writeTo(), and should assume that the user has already constructed the Vec with the appropriate size.

Since (i) our method returns nothing to its caller, (ii) it needs to “know” the istream from which it is to read, (iii) it modifies that istream by extracting items, and (iv) it might modify its instance variables, we might begin with this stub:

void Vec::readFrom(istream& in) {
}

Place a prototype for this method in the Vec class, and in tests.cpp, uncomment the test TEST_CASE("readFromStream"). Then add statements to this stub so that it passes the test.

Assuming that mySize equals the number of values in in, the Vec readFrom(istream& in) method should:

Continue when your method passes all the tests. (My solution passes with 82 assertions in 9 test cases. If you have less, uncomment TEST_CASE("getSize")).

Submit

Use VSCode (or the command line) to commit and push your changes to your repo.

To verify your submission to github.com, go to a browser and go to the location of your repo in github.com.

Also, verify that your submission passes all the automated tests in github. The automated tests are the same as those in tests.cpp.

Grading Rubric

24 pts total

Ways students lost points in the past:
